ACHI 4000
Side-opening doors system ACHI 4000
Description
Electro-mechanical endless mechanism for sliding doors and three-phase motor.
Heavy-duty use.
ACHI 4000: Mechanism for sliding doors 4000Kg.
- With irreversible reduction and oil bath.
- Three-phase, mechanical friction, and self-ventilated.
- With built-in panel.
ACHI 4000: Mechanism for sliding doors 4000Kg.
| ACHI 4000 | |
| Power supply | 400V / 50Hz |
| Absorbed current | 3.75 A |
| Motor power supply | 400V three-phase |
| Motor power | 1500W |
| Motor revolutions | 1400 rpm |
| Reduction ratio | 1/30 |
| Minimum speed at maximum load | 11m/min |
| Operating temperature | -20 to +60ºC |
| Duty cycle | 80/20% |
| Protection level | IP 44 |
| Maximum thrust force | 3200N |
| Maximum gate weight | 4000Kg. |
| Weight | 59Kg. |
Electro-mechanical endless mechanism for sliding doors and three-phase motor.
Heavy-duty use.
ACHI 4000: Mechanism for sliding doors up to 4000Kg.
- With irreversible reduction and oil bath.
RECOMMENDED KITS
STANDARD KIT:
‐ STANDARD KIT: 1 ACHI 4000 (INCORPORATED CONTROL PANEL) + 1 TR255 MINI + 4 MTRS CR 260 + 1 TE2 + 2 CF 10 E or 2 CF‐EVE.
ACCESSORIES
CONTROL PANEL CTS, CTC, TRAFFIC LIGHT SEM 1‐2, LAMP
