COMEC 20 M
Side-opening doors system COMEC 20 M
Description
Electro-mechanical endless mechanism for automating sliding doors.
Heavy-duty use.
COMEC 20 M: Industrial sliding gates of ≈ 2000Kg.
- WITH ENCODER AND BUILT-IN ANTI-CRUSHING SYSTEM.
- SLOW SPEEDS AND ADJUSTABLE SOFT STOP.
- PROGRAMMING BY SELF-LEARNING.
- Guaranteed number of maneuvers thanks to its self-ventilation.
- High-strength material reduction elements fully immersed in grease.
- Limit switches; supplied at 230v or 120v.
- BUILT-IN PANEL.
- Irreversible. Ensures a perfect closing of the gate without using an electro-lock.
- A personalized key release allows manual operation of the gate in the absence of power.
COMEC 20M: Industrial sliding gates up to approximately 2000 kg.
COMEC 5 CC | |
Power supply | 230V, 50Hz / 120V, 60Hz |
Motor power | 480W |
Current absorption | 3.5A |
Starting force | 50Nm |
Protection degree | IP 54 |
Insulation class | F |
Thermo-protection intervention | 150ºC |
Operating temperature | -20º/+70ºC |
Max. gate weight | 2000KG |
Speed | 10.5m/min |
Capacitor | 31.5μƒ |
Lubrication | AGIP BLASIA 100 GREASE |
Rack module | M4 |
Weight | 17KG |
Mechanism for automating endless electro-mechanical sliding doors.
Intensive use.
COMEC 20 M: Industrial sliding gates of approximately 2000Kg.
- WITH BUILT-IN ENCODER AND ANTI-CRUSHING SYSTEM.
- SLOW SPEEDS AND ADJUSTABLE SOFT STOP.
- PROGRAMMABLE THROUGH SELF-LEARNING.
- BUILT-IN CONTROL PANEL.
KITS RECOMENDED
KIT STANDARD:
‐ KIT STANDARD: 1 COMEC 20 M (ENCODER AND BUILT-IN PANEL) + 4 MTRS CR 260 + 1 TE2 + 2 CF 10 E or 2 CF-EVE.
ACCESSORIES
TRAFFIC LIGHT SEM 1-2, FLASHING LAMP LO1E 220, REMOTE CONTROL TE2, TE3, TE4, GO2, PHOTOCELLS CF 10 E, CF 10, CR P 700, CR P 300, C 3/8”.
