EXPY
Side-opening doors system EXPY
Description
Motor reducer for automating sliding doors.
ENCODER WITH BUILT-IN ANTI-CRUSHING
Limited collective use.
- EXPY 600: Motor reducer for sliding doors up to 600Kg.
- EXPY 800: Motor reducer for sliding doors up to 800Kg.
Models with built-in control panel.
Endless mechanism.
Electro-mechanical equipment
- EXPY 600: Gearmotor for sliding doors up to 600Kg.
- EXPY 800: Gearmotor for sliding doors up to 800Kg.
| EXPY 600 | EXPY 800 | |
| Power supply | 230V, 50Hz / 120V, 60Hz | 230V, 50Hz / 120V, 60Hz |
| Absorption of line | 1.3 A | 1.4 A |
| Power | 250W | 270W |
| Capacitor | 12.5μF | 12.5μF |
| End of travel | Electromechanical | Electromechanical |
| Mechanical release | With key | With key |
| IP protection rating | 44 | 44 |
| Motor rotation RPM | 1400 | 1400 |
| Operating temperature | -20º +55ºC | -20º +55ºC |
| Maximum leaf weight | 600KG | 800KG |
| Opening speed | 10 m/min | 10 m/min |
| Opening time | 50% | 50% |
Gearmotor to automate sliding doors.
ENCODER WITH BUILT-IN ANTI-PINCHING
Limited collective use.
Models with built-in control panel.
Endless mechanism.
Electro-mechanical equipment.
KITS RECOMENDADOS
KIT STANDARD:
‐ KIT STANDARD: 1 EXPY MODELO A ESCOGER (ENCODER, CUADRO Y TARJETA INCORPORADOS) + 4 MTRS CR 260 + 1 TE2 + 2 CF 10 E ó 2 CF‐EVE.
ACCESORIOS
SEMÁFORO SEM 1‐2, LÁMPARA DE DESTELLOS LO1E 220, MANDO TE2, TE3, TE4, GO2, FOTOCELULAS CF 10 E, CF 10, CR P 700, CR P 300, C 3/8”
