COMEC CC
Side-opening doors system COMEC CC
Description
24V electro-mechanical equipment for automating sliding doors.
Heavy-duty use.
- COMEC CC: 24V motor (allows automation of high-traffic doors).
- The tilting of the COMEC CC mechanism allows it to be adapted to sliding doors with deficiencies in the installation of racks or ground sinking.
- It adapts to 20×20 or 30×12 racks by moving the unlocking lever.
- By changing the roller, the equipment is suitable for nylon racks.
- Ultra-fast unlocking.
- With encoder. End-of-travel switches unnecessary.
- Adjustable anti-crushing, allowing stopping or reversing.
- Completely waterproof IP65 control panel.
- SOFT STOP in closing and opening.
- Elimination of pinion shaft bending through bearing.
- Compatible with the use of BATTERIES AND SOLAR PANELS.
| COMEC CC | |
| Power supply | 24 Vdc |
| Power | 73W |
| Current | 2A |
| Operation | Intensive |
| Driving pinion | M4-Z 12 |
| Torque | 12.5 Nm |
| Door weight | 500kg |
| Drag | 50kg |
| Speed | 12m/min |
| Protection | IP 30 |
| Temperature | -20º to +80º C |
24V electro-mechanical mechanism for automating sliding doors.
Intensive use.
- COMEC CC: 24V motor (allows automation of high-traffic doors).
- …
KITS RECOMMENDED
STANDARD KIT:
‐ STANDARD KIT: 1 COMEC CC (INCORPORATED CONTROL PANEL AND BOARD) + 4 MTRS CR 260 + 1 TE2 + 2 CF 10 E or 2 CF‐EVE.
ACCESSORIES
SEM 1‐2 TRAFFIC LIGHT, LO1E 220 FLASHING LAMP, REMOTE CONTROLS TE2, TE3, TE4, GO2, PHOTOCELLS CF 10 E, CF 10, CR P 700, CR P 300, C 3/8”.
