Global Tor
Swing doors system Global Tor
Description
Features
Extra Features (depending on model)
Except for the soft stop at the shaft entrance and the Genio technology, this equipment already has all the existing features, and thanks to its “global technology,” it is possible to configure all of them according to your needs, even being able to adjust the intensities of the locks, allowing the automation of any type of swing gate without the need for a prior study.
Usage Level: Collective
Description
COLLECTIVE OR INTENSIVE USE. ABSOLUTE LINEAR ENCODER.
- Allows the operation of single or double leaf swing gates.
- Hermetic hydraulic circuit. No purging required.
- No risk of leaks.
- For gates with a maximum leaf length of ~5.5 meters and a maximum weight of 700Kg.
Thanks to the significant advancement achieved in the engineering department and through constant investments in R&D, a unique and non-existent motor has been created in the market.
This name reflects the significant advantage over other existing swing gate motor sets in the market today, as this motor has all the functions of the available swing gate motors (REVERSIBLE, IRREVERSIBLE, RETENTIONS, ETC).
This new technology allows for the automation of any type of swing gate with just a single motor model, thus allowing for stock unification that will greatly facilitate our customers’ purchasing forecasts.
| GLOBAL TOR | |
| Power Supply | 230V, 50Hz / 120V, 60Hz |
| Power | 276 W |
| Current Absorbed | 1.2 A |
| R.P.M | 1450 |
| Protection Level | IP 55 |
| Operating Temperature | -20ºC / +80ºC |
| Operating Service | Collective |
| Flow Rate | 0.7 l/min |
| Working Pressure | 0 / 60 bars |
| Linear Opening Force | 5420 N |
| Linear Closing Force | 7540 N |
| Stroke | 250 mm / 400 mm |
| Weight | 10 kg |
| Damping | In closing (adjustable in speed and stroke) |
| Closure | With lock / Hydraulic lock |
| Opening Speed | 18 s |
| Closing Speed | 22 s |
COLLECTIVE OR INTENSIVE USE. ABSOLUTE LINEAR ENCODER.
- Allows operation of swing gates with 1 or 2 leaves.
- Hermetic hydraulic circuit. No purging required.
- No risk of leaks.
- For gates with a maximum leaf length of ~ 5.5m and a maximum weight of 700kg.
RECOMMENDED KITS
STANDARD KITS
STANDARD SINGLE LEAF KIT
STANDARD DOUBLE LEAF KIT
KITS WITH HYDRAULIC LOCK
HYDRAULIC EXIT SINGLE LEAF KIT
NOTE: For doors under 2.5 meters, it is possible to dispense with the lock (in single-leaf installations) and the lock and latch (in two-leaf installations) if the equipment is set up with the lock in the closed door position.
DOUBLE LEAF HYDRAULIC OUTPUT KIT
NOTE: For doors under 2.5 meters, it is possible to dispense with the lock (in single-leaf installations) and the lock and latch (in two-leaf installations) if the equipment is set up with the lock in the closed door position.
